• Year
  • 1952
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 147340

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 4-B-67 Code 120-2-F152 - Firestone Tire & Rubber Co.
  • Shape
  • Chassis only or for «building in»
  • Notes
  • The Firestone Model 4-B-67 is a Battery Operated 6 Tube AM Superheterodyne Receiver for 1952 Ford Automobiles.
    Vibrator for +B.
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.
