• Country
• United States of America (USA)

• Manufacturer / Brand
• Fisher Radio; New York (NY)

• Year
• 1961–1963 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 100573

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 19

• Valves / Tubes
• ECC85 EF94 EF94 EF94 EM84a EF94 ECC81 ECC83 ECC81 ECC83 ECC83 ECC83 ECC83 ECC83 7591 7591 7591 7591

• Main principle
• Superhet with RF-stage

• Wave bands
• FM Broadcast Band Only

• Details
• Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 105-120 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 65 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Wide-Band FM Multiplex Receiver 500-B - Fisher Radio; New York NY

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 26 x 14 x 20 inch / 660 x 356 x 508 mm

• Notes

• FM receiver with 'Stereo Beam'.

• Net weight (2.2 lb = 1 kg)
• 1.2 kg / 2 lb 10.3 oz (2.643 lb)

• Price in first year of sale
• 359.50 USD

• Source of data
• -- Collector info (Sammler)

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
