Closed 3-way Box Speaker SME-170

Fisher Radio; New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1980 ?
  • Category
  • Loudspeaker, headphone or earphone
  • Radiomuseum.org ID
  • 350895

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • 3 Loudspeakers
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Closed 3-way Box Speaker SME-170 - Fisher Radio; New York NY
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 230 x 430 x 190 mm / 9.1 x 16.9 x 7.5 inch
  • Notes

  • Fisher Closed 3-way Box Speaker model SME-170

    1x TT 200mm
    1x MT 100mm
    1x HT 60 mm
    Crossover frequency: 3000 / 8000 Hz
    Gross volume 21.3 liters.

    Frequency response 42 - 20000 Hz
    Rated / music load capacity 50 / 75 W

    Nominal impedance 4 - 8 ohms

  • Net weight (2.2 lb = 1 kg)
  • 6 kg / 13 lb 3.5 oz (13.216 lb)
  • Price in first year of sale
  • 198.00 DM
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
