RS-1058

• Country
• United States of America (USA)

• Manufacturer / Brand
• Fisher Radio; New York (NY)

• Year
• 1977

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 147975

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 180 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: RS-1058 - Fisher Radio; New York NY

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 530 x 180 x 360 mm / 20.9 x 7.1 x 14.2 inch

• Notes
• AM/FM-Stereo-Receiver mit 2 x 90 Watt Sinus an 4 Ohm.

• Net weight (2.2 lb = 1 kg)
• 14.7 kg / 32 lb 6.1 oz (32.379 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
