Digital Multimeter 8000A
Fluke, John, Mfg. Co. Inc.; Everett (WA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Fluke, John, Mfg. Co. Inc.; Everett (WA)
- Year
- 1972–1976
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 176534
Fluke 8000A front.
Collection Privée - Patrice Schoser
Fluke 8000A Bottom / label.
IC TTL 7447 from year 73 week 50.
IC's from year 75 weeks 19 and 37.
Battery charging.
Collection Privée - Patrice Schoser
Collection Privée - Patrice Schoser
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Line / Storage batteries (perhaps also batteries) / 115; 230 / 4 x 1,5 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Digital Multimeter 8000A - Fluke, John, Mfg. Co. Inc.;
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 217 x 64 x 271 mm / 8.5 x 2.5 x 10.7 inch
- Notes
- The Fluke Digital Multimeter 8000A measures AC and DC voltages up to 1200 V, AC and DC current to 2000 mA and resistance up to 20 MΩ. 3 1/2 digit LED display.
- Net weight (2.2 lb = 1 kg)
- 2.1 kg / 4 lb 10 oz (4.626 lb)
- Price in first year of sale
- 7,950.00 öS
- Source of data
- - - Data from my own collection
- Mentioned in
- (A) Radio Elektronik Schau Heft 11 1975 Werbeschaltung
- Author
- Model page created by Francisco Gallego. See "Data change" for further contributors.
