Multimeter Serie II 70
Fluke, John, Mfg. Co. Inc.; Everett (WA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Fluke, John, Mfg. Co. Inc.; Everett (WA)
- Year
- 1991
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 239420
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Dry Batteries / 1 x 9 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Multimeter Serie II 70 - Fluke, John, Mfg. Co. Inc.;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 75 x 28 x 166 mm / 3 x 1.1 x 6.5 inch
- Notes
-
Spannung: 300 mV bis 1000 VDC, 750 VAC;
Strom: 10 A DC/AC;
Widerstand: 0,1–32 MOhm;
Durchgangsprüfung-Signalton: 4096 Hz;
Automatische Bereichswahl, automatischer Festhalte-Betrieb;
Diodenprüfung;
Digital- und Balkenanzeige.See also Fluke Multimeter 73
- Net weight (2.2 lb = 1 kg)
- 0.3 kg / 0 lb 10.6 oz (0.661 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
