True RMS Digital Multimeter 87V

• Country
• United States of America (USA)

• Manufacturer / Brand
• Fluke, John, Mfg. Co. Inc.; Everett (WA)

• Year
• 2015

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 283830

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / PP3: 1 x 9 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: True RMS Digital Multimeter 87V - Fluke, John, Mfg. Co. Inc.;

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Notes

• Gama de Medición:
  VAC: 1000 V
  VDC: 1000 V
  AAC: 10 A
  ADC: 10 A
  OHMS: 50 MΩ
  CAP: 9,999 µF
  Diode: 3 V
  Freq: 200 kHz

• Author
• Model page created by Miguel Lopez. See "Data change" for further contributors.
