UKW-Retroradio zum Selberbauen

Franzis Verlag, München

Data
Forum
Pictures
Collections

  • Year
  • 2010 ?
  • Category
  • Kit (Parts plus instruction) or building instructions only
  • Radiomuseum.org ID
  • 247719

 Technical Specifications

  • Number of Transistors
  • 2
  • Main principle
  • Superheterodyne (common); ZF/IF 70 kHz
  • Wave bands
  • FM Broadcast Band Only
  • Power type and voltage
  • Dry Batteries / 2 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
  • Material
  • Special material, described in the notes.
  • from Radiomuseum.org
  • Model: UKW-Retroradio zum Selberbauen - Franzis Verlag, München
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 160 x 111 x 48 mm / 6.3 x 4.4 x 1.9 inch
  • Notes

  • Kompletter Bauatz eines UKW-Radios im Pappgehäuse mit Magnetverschluss;
    Empfang über Teleskopantenne; Kapazitätsdioden-Abstimmung über Potentiometer
    (87,5 bis 108 MHz).

  • Net weight (2.2 lb = 1 kg)
  • 0.228 kg / 0 lb 8 oz (0.502 lb)
  • Price in first year of sale
  • 29.95 EUR
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Michael Mischke. See "Data change" for further contributors.
