• Country
• Soviet Union

• Manufacturer / Brand
• Frunze Radio Works, Gorky, now Nizhnij Novgorod

• Year
• 1948

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 113029

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 6С5 6К7 6Х6С 6Х6С 6Г7 6Ф6С 6Ц5С

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 100-140; 170-250 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Standard signal generator GSS-6 - ГСС-6 - Frunze Radio Works, Gorky, now

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 557 x 334 x 322 mm / 21.9 x 13.1 x 12.7 inch

• Notes
• AM signal generator 100 to 250000 kHz in eight ranges, 0,1 mV - 1 V output at 0.8, 8 and 40 Ohms.

• Net weight (2.2 lb = 1 kg)
• 20 kg / 44 lb 0.8 oz (44.053 lb)

• Source of data
• - - Data from my own collection

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Zenonas Langaitis. See "Data change" for further contributors.
