Netzteil für Fernspeisung -24 V TKN790-01
Fuba, Hans Kolbe; Bad Salzdetfurth
- Country
- Germany
- Manufacturer / Brand
- Fuba, Hans Kolbe; Bad Salzdetfurth
- Year
- 1986 ??
- Category
- Power supply/conditioner or battery or charger
- Radiomuseum.org ID
- 326661
- Number of Transistors
- 3
- Semiconductors
- B60C800
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Netzteil für Fernspeisung -24 V TKN790-01 - Fuba, Hans Kolbe; Bad
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 125 x 85 x 45 mm / 4.9 x 3.3 x 1.8 inch
- Notes
-
Netzteil ~220 V/ -24 V/60 mA max. 5 W mit IEC Ein- und Ausgang zur Speisung von Vorverstärkern im VHF/UHF- und UKW-Bereich.
- Net weight (2.2 lb = 1 kg)
- 0.225 kg / 0 lb 7.9 oz (0.496 lb)
- Author
- Model page created by Ralf Rehbein. See "Data change" for further contributors.
