• Country
• Germany

• Manufacturer / Brand
• Funkschau, Franzis-Verlag; München

• Year
• 1957–1959

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 200334

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Minograf 457 - Funkschau, Franzis-Verlag;

• Shape
• Tablemodel, with any shape - general.

• Notes
• Bauanleitung in Funkschau 1957 Heft 24,
  Ergänzung in Funkschau 1959 Heft 7

• Mentioned in
• Funkschau (1957 Heft 24 + 1959 Heft 7)

• Author
• Model page created by Heribert Jung. See "Data change" for further contributors.

• Other Models

• Here you find 26 models, 24 with images and 23 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Funkschau, Franzis-Verlag; München
