• Country
• Germany

• Manufacturer / Brand
• Funkwerk Dresden, VEB, RFT (Ostd. vorm. H. Mende & Co.)

• Year
• 1962

• Category
• Commercial Receiver (may include amateur bands)

• Radiomuseum.org ID
• 118324

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• ECC85 EF89 EF89 EF89 EAA91 ECL82

• Main principle
• Superhet with RF-stage; ZF/IF 3100 kHz; 2 AF stage(s)

• Tuned circuits
• 12 FM circuit(s)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.1 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Rundspruchempfänger 1355.AA - Funkwerk Dresden, VEB, RFT

• Dimensions (WHD)
• 370 x 240 x 150 mm / 14.6 x 9.4 x 5.9 inch

• Notes

• Rundspruchempfänger, FM, Empfangsfrequenz: 41,0 ... 41,7 MHz, fest eingestellt.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Wolfgang Lill. See "Data change" for further contributors.
