Megohmmeter 005a
Funkwerk Erfurt, VEB, RFT (Ostd.) - vorm. Telefunken GmbH
- Country
- Germany
- Manufacturer / Brand
- Funkwerk Erfurt, VEB, RFT (Ostd.) - vorm. Telefunken GmbH
- Year
- 1958
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 191544
-
- Brand: FWE
Bild aus Bedienungsvorschrift.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- EF85 StR150/20 EW4-12V/0,5A
- Number of Transistors
- Semiconductors
- Tr.Gl.=Metal-rectif.
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 120; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Megohmmeter 005a - Funkwerk Erfurt, VEB, RFT Ostd
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 220 x 280 x 170 mm / 8.7 x 11 x 6.7 inch
- Notes
- Weiterentwicklung des Typ 005. Messbereich 0,1...5000 MOhm ± 10% in 4 Bereichen. Messung mit 75V Gleichspannung an erdfreien Objekten. Das Anzeigeinstrument ist unmittelbar in MOhm geeicht.
- Net weight (2.2 lb = 1 kg)
- 4 kg / 8 lb 13 oz (8.811 lb)
- Price in first year of sale
- 490.00 Mark
- Source of data
- - - Manufacturers Literature
- Mentioned in
- Angebotsliste 1962 Elektr. Mess- und Prüfgeräte VKM
- Author
- Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
