UKW Meßgenerator 2006a
Funkwerk Erfurt, VEB, RFT (Ostd.) - vorm. Telefunken GmbH
- Country
- Germany
- Manufacturer / Brand
- Funkwerk Erfurt, VEB, RFT (Ostd.) - vorm. Telefunken GmbH
- Year
- 1963
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 123013
-
- Brand: FWE
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Number of Transistors
- Semiconductors
- HRW6/5
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 120/220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: UKW Meßgenerator 2006a - Funkwerk Erfurt, VEB, RFT Ostd
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 550 x 495 x 405 mm / 21.7 x 19.5 x 15.9 inch
- Notes
- Trägerfrequenz 10 MHz - 240 MHz, unterteilt in 10 Bereiche. Ausgangsspannung 50 mV -0,5 µV an 60 Ohm, Eigenmodulation 1000 Hz, Fremdmodulation 20 Hz - 100 kHz, Leistungsaufnahme ca. 130 Watt.
- Net weight (2.2 lb = 1 kg)
- 38 kg / 83 lb 11.2 oz (83.7 lb)
- Price in first year of sale
- 5,865.00 DM
- Author
- Model page created by a member from D. See "Data change" for further contributors.
