Universal-Röhrenvoltmeter 187A

• Country
• Germany

• Manufacturer / Brand
• Funkwerk Erfurt, VEB, RFT (Ostd.) - vorm. Telefunken GmbH

• Year
• 1959

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 75968

• • Brand: FWE

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• EAA91 EF86 EF86 ECC81 StR108/30 StR108/30

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Universal-Röhrenvoltmeter 187A - Funkwerk Erfurt, VEB, RFT Ostd

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 410 x 250 x 280 mm / 16.1 x 9.8 x 11 inch

• Notes

• Messbereiche: 0,3-300 V DC; 0,2-100 V AC; Spannungsmessungen bis 50 kV durch spezielle Zusatzgeräte möglich; Messfehler: 3-5%.

• Price in first year of sale
• 1,575.00 Mark

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Mentioned in
• Funk-Technik (FT) (1. Mailheft Nr. 9/1960 Werbung)

• Literature/Schematics (1)
• Angebotsliste Versorgungskontor, 2.Halbj.1962

• Author
• Model page created by Bernd Pötzsch. See "Data change" for further contributors.
