• Year
  • 1969–1971
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 87062
    • alternative name: Radio- und Metallw.; Zittau

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 12
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 110, 127, 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 4 W (unknown quality)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Perfekt 406 - Funkwerk Zittau, VEB, RFT, -
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 592 x 194 x 350 mm / 23.3 x 7.6 x 13.8 inch
  • Notes
  • Phono-Koffer mit Stereo-Verstärker, getrennte H/T-Regler, separater Verstärker-Eingang, 2 externe LS-Boxen (15 Ω) als abnehmbarer Deckel für Transport. Chassis Perfekt 006, 16/33/45/78 UpM. Rohrtonarm mit Stereo-Kristall-Abtastsystem KSS 0163 oder für Normalrille KSM 0161N, Tonarmlift. Stereo-Ausgang mit DIN-Stecker.
    Technisch wie Modell Perfekt 506.
  • Net weight (2.2 lb = 1 kg)
  • 14 kg / 30 lb 13.4 oz (30.837 lb)
  • Price in first year of sale
  • 625.00 DM
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Mentioned in
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • Funkverlag Hein, Service-DVD
  • Literature/Schematics (2)
  • radio fernsehen elektronik 1969, H. 2, S.43
  • Author
  • Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
