• Country
• Germany

• Manufacturer / Brand
• Phonotechnik Pirna/Zittau; VEB; (Ostd.); Marke: Ziphona

• Year
• 1980/1981

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 82345

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Wooden case

• from Radiomuseum.org
• Model: MA224 - Phonotechnik Pirna/Zittau; VEB

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 395 x 140 x 335 mm / 15.6 x 5.5 x 13.2 inch

• Notes

• Zarge, 33 und 45 U/min, Flachriemenantrieb, System CS24SD, dunkle Acrylglashaube abnehmbar, 5-poliger Diodenstecker, Stereowiedergabe, manuelle und automatische Tonarmsteuerung.

  Gehäusevarianten: Holz mit Dekorfolie oder farbgespritzt.

• Net weight (2.2 lb = 1 kg)
• 4 kg / 8 lb 13 oz (8.811 lb)

• Price in first year of sale
• 380.00 DM

• Source of data
• -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb

• Mentioned in
• Sortimentskatalog Elektroakustik (DDR, 1987)

• Author
• Model page created by Wolfgang Lill. See "Data change" for further contributors.
