Tunable Notch Filter Rejector
Galaxy Electronics, Council Bluffs (IA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Galaxy Electronics, Council Bluffs (IA)
- Year
- 1965
- Category
- Amateur Equipment (Other, but not Key)
- Radiomuseum.org ID
- 288994
QST April 1965 page 131
QST April 1965 page 131
- Number of Transistors
- 7
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Powered by external power supply or a main unit.
- Loudspeaker
- - For headphones or amp.
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Tunable Notch Filter Rejector - Galaxy Electronics, Council
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 7.5 x 2.5 x 5.375 inch / 191 x 64 x 137 mm
- Notes
-
The Galaxy Rejector is a tunable notch filter with a range of 300 to 5000 cycles. It also has an amplifier with a 6 db gain. The unit's faceplate is reversible for horizonal or vertical positions. It requires 12 volts AC or DC at 0.5 amps. An optional 115 VAC power supply was available.
- Price in first year of sale
- 34.95 USD
- Mentioned in
- QST (April 1965 page 131)
- Author
- Model page created by Wayne Childress. See "Data change" for further contributors.
