Coronado 15TV1-43-9020A
Gamble-Skogmo, Inc.; Minneapolis, MN
- Country
- United States of America (USA)
- Manufacturer / Brand
- Gamble-Skogmo, Inc.; Minneapolis, MN
- Year
- 1952 ?
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 354263
-
- Brand: Coronado
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 24
- Valves / Tubes
- 6AG5 12AT7 6AU6 6AU6 6AU6 6AU6 6AL5 12AT7 6AU6 6AU6 6AL5 6AU6 6V6GT 6SN7GT 6SN7GT 6AL5 6SN7GT 6BG6G 6W4GT 1X2 5U4G 6BE6 6BA6 17BP4
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: Coronado 15TV1-43-9020A - Gamble-Skogmo, Inc.;
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Coronado model 15TV1-43-9020A is a 17” b/w TV with US standard VHF tuner channels 2 thru 13.Equipped with an AM radio receiver, a VHF tuner and picture tube 17BP4.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 161, folder 3, dated 2-52)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
