Coronado TV1-9411A
Gamble-Skogmo, Inc.; Minneapolis, MN
- Country
- United States of America (USA)
- Manufacturer / Brand
- Gamble-Skogmo, Inc.; Minneapolis, MN
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 258013
-
- Brand: Coronado
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 15
- Valves / Tubes
- 4BQ7A 5BR8 3CB6 3CB6 5AN8 12BY7A 5AN8 3BN6 5AQ5 6CM7 6CG7 25CD6G 19AU4 1B3GT 21ALP4B or 21AVP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 110-120 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 5.25 inch = 13.3 cm
- from Radiomuseum.org
- Model: Coronado TV1-9411A - Gamble-Skogmo, Inc.;
- Notes
-
The Coronado TV1-9411A is a 21" b/w TV with US standard VHF Tuner channels 2 thru 13. Equipped with picture tube 21ALP4B or 21AVP4A. Uses Qty(2) PM 5.25" speakers.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 361, Folder 4 dated 6-57)
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 340 Folder 22-S Dated 56)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
