TV1-9305A Code 17T24
Gamble-Skogmo, Inc.; Minneapolis, MN
- Country
- United States of America (USA)
- Manufacturer / Brand
- Gamble-Skogmo, Inc.; Minneapolis, MN
- Year
- 1956 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 278260
-
- Brand: Coronado
Picture from service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 15
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: TV1-9305A Code 17T24 - Gamble-Skogmo, Inc.;
- Shape
- Tablemodel, with any shape - general.
- Notes
-
The Coronado Model TV1-9305 Code 17T24 is a 17 " b/w TV with US standard VHF tuner channels 2 thru 13 with picture tube 17HP4.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 335 Folder 5 dated 10-56)
- Literature/Schematics (2)
- Photofact Folder, Howard W. SAMS (Set 314 Folder 13-S dated 1956)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
