• Country
• Great Britain (UK)

• Manufacturer / Brand
• Garrard Eng. & Mfg. Co. Ltd.; Swindon, England

• Year
• 1968 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 240964

Click on the schematic thumbnail to request the schematic as a free document.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 110-125; 220-240 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: Automatic Transcription Changer SL72B - Garrard Eng. & Mfg. Co. Ltd.;

• Dimensions (WHD)
• 370 x 178 x 322 mm / 14.6 x 7 x 12.7 inch

• Notes

• Synchronous motor with rubber idler/intermediate wheel drive to turntable.

  Record speeds: 33.3, 45 and 78 rev/min.

  Stylus force: 0 to 5 gm.

• Mentioned in
• - - Manufacturers Literature (Manufacturer data sheet)

• Author
• Model page created by Stan Roberts. See "Data change" for further contributors.
