• Country
• Italien / Italy

• Manufacturer / Brand
• GBC; Milano

• Year
• 1959/1960

• Category
• Rundfunkempfänger (Radio - oder Tuner nach WW2)

• Radiomuseum.org ID
• 118515

• • anderer Name: Gian Bruto Castelfranchi

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• ECC85 ECH81 EF85 EABC80 EM84

• Main principle
• Superhet allgemein

• Wave bands
• Langwelle, Mittelwelle und UKW (FM).

• Details
• HF-Drahtfunk (Telefonrundspruch)

• Power type and voltage
• Wechselstromspeisung / 110; 125; 140; 160; 220 Volt

• Lautsprecher
• - Für Kopfhörer oder NF-Verstärker

• from Radiomuseum.org
• Model: SM1254 - GBC; Milano

• Form
• Chassis - Einbaugerät

• Notes
• Sintonizzatore AM/FM e filodiffusione. Rettificatore selenio 60mA

• Mentioned in
• GBC, Selezione di tecnica radio-tv, Dicembre 1959

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
