Centralino amplificatore G1532C
Geloso SA; Milano
- Country
- Italy
- Manufacturer / Brand
- Geloso SA; Milano
- Year
- 1959
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 122155
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 13
- Main principle
- Superheterodyne (common); ZF/IF 467/10700 kHz
- Wave bands
- Broadcast, 2 Short Wave plus FM or UHF.
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220; 280 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Power out
- 75 W (100 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: Centralino amplificatore G1532C - Geloso SA; Milano
- Shape
- Rack
- Dimensions (WHD)
- 650 x 1360 x 420 mm / 25.6 x 53.5 x 16.5 inch
- Notes
- Complesso centralizzato composto da: sintonizzatore FM/OM G.535, amplificatore G.274A, giradischi 2240/4 a quattro velocità, un altoparlante spia diametro 20 cm, possibilità di inserire un registratore. 48 linee di uscita per altrettanti altoparlanti ognuna inseribile o disinseribile.
- Net weight (2.2 lb = 1 kg)
- 124 kg / 273 lb 2 oz (273.128 lb)
- Literature/Schematics (1)
- Bollettino Tecnico Geloso (n. 75, estate 1959)
- Author
- Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
