G108

• Country
• Italy

• Manufacturer / Brand
• Geloso SA; Milano

• Year
• 1954/1955

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 85051

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AV6 50B5 35X4

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110, 125, 140, 160, 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

• Power out
• 2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: G108 - Geloso SA; Milano

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 490 x 280 x 210 mm / 19.3 x 11 x 8.3 inch

• Notes
• 5 gamme d'onda: OM (180/580m) e 4 OC di tipo allargato (50-31-25-19m).
  Altoparlante magnetodinamico Geloso SP125 da 127mm.
  Gruppo A.F. Geloso 2662-F.

  5 wave bands: BC + 4 SW.
  Magnet dynamic loudspeaker: Geloso SP125.

• Source of data
• Guida Pratica Antique Radio III (2000)

• Mentioned in
• -- Original prospect or advert (Catalogo Generale Radioprodotti Geloso 1954-55, p. 178)

• Literature/Schematics (1)
• Riparazioni - Scuola Radio Elettra (pag. G6)

• Author
• Model page created by Alessandro De Poi. See "Data change" for further contributors.
