G91SW
Geloso SA; Milano
- Country
- Italy
- Manufacturer / Brand
- Geloso SA; Milano
- Year
- 1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 121695
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superhet with RF-stage; ZF/IF 467 kHz
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 140; 160; 220; Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 12 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: G91SW - Geloso SA; Milano
- Shape
- Console: Chairside Radio.
- Notes
- circuito uguale al G91, ma con tre gamme di onde corte e senza onde lunghe.
- Price in first year of sale
- 1,200.00 LIT
- Literature/Schematics (1)
- Bollettino Tecnico Geloso (n. 31 inverno 1939)
- Author
- Model page created by Giuseppe Antonio Tusini. See "Data change" for further contributors.
