• Country
• Italy

• Manufacturer / Brand
• Geloso SA; Milano

• Year
• 1955/1956 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 165581

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• UCH81 UF41 UBC41 UL41 DM70 UY41

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Material
• Bakelite case

• from Radiomuseum.org
• Model: G.301-B [avorio] - Geloso SA; Milano

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 250 x 150 x 120 mm / 9.8 x 5.9 x 4.7 inch

• Notes

• Onde Medie e 4 gamme allargate di onde Corte, 49, 31, 25 e 19 metri.
  Versione bianco-avorio della G 301-M.


• Net weight (2.2 lb = 1 kg)
• 2.2 kg / 4 lb 13.5 oz (4.846 lb)

• Price in first year of sale
• 24,500.00 ITL

• Mentioned in
• Catalogo ANIE (1955-56)

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Enrico Puccini. See "Data change" for further contributors.
