- Country
- Canada
- Manufacturer / Brand
- General Motors of Canada; Oshawa
- Year
- 1948/1949
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 181496
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 465 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: 466 - General Motors of Canada;
- Shape
- Chassis only or for «building in»
- Notes
- Vibrator for +B. Push-button tuning.
- Circuit diagram reference
- Radio College of Canada
- Literature/Schematics (1)
- Canada schematics General Motors page 14 to 16
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
