10C102

General Electric Co. (GE); Bridgeport CT, Syracuse NY

Data
Forum
Pictures
Collections

  • Year
  • 1949/1950
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 170359
    • Brand: Musaphonic

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 20
  • Main principle
  • Superheterodyne (common); ZF/IF 45750/4500 kHz
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 115 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
  • Power out
  • 1 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 10C102 - General Electric Co. GE;
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 17.3 x 33.1 x 20.9 inch / 439 x 841 x 531 mm
  • Notes
  • General Electric 10" TVs model 10C101 (mahogany) and 10C102 (blond) are identical except for cabinet color. Both use the same chassis as the 10T1 "Locomotive" with 12 channel VHF tuner.

    According to Rider TV, sets manufactured after January 1950 use 6BC5 tubes in place of 6AG5.
  • Circuit diagram reference
  • Photofact Folder, Howard W. SAMS
  • Literature/Schematics (1)
  • Rider TV GE 5-1; SAMS set 96 folder 4
  • Author
  • Model page created by Thomas Albrecht. See "Data change" for further contributors.
