• Country
• United States of America (USA)

• Manufacturer / Brand
• General Electric Co. (GE); Bridgeport CT, Syracuse NY

• Year
• 1955 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 81596

• • Brand: Musaphonic

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 1R5 1U4 1U5 3V4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage and/or dry batteries / 1.5/75 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• from Radiomuseum.org
• Model: 667 - General Electric Co. GE;

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Notes

• The General Electric P701 is a battery operated 4 tube BC band receiver.  BC band range is 540 to 1600kHz.  Has built-in loopstick antenna. Uses Qty(2) 1.5V batteries and Qty(1) 75V battery.  The 1.5V "A" battery used is Eveready 954, Burgess 21R or equivalent.  The 75V "B" battery used is Eveready 437, Burgess XX50 or equivalent.

  This model 667 from General Electric (GE) is quite similar to the models P-700 and P-701.

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 16, 1956

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
