- Country
- United States of America (USA)
- Manufacturer / Brand
- General Electric Co. (GE); Bridgeport CT, Syracuse NY
- Year
- 1966
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 100356
-
- Brand: Musaphonic
Picture from General Electric Service Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 60 cycles, 105 to 120 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: C-1450A - General Electric Co. GE;
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Dimensions (WHD)
- 12.75 x 7 x 5.75 inch / 324 x 178 x 146 mm
- Notes
-
The General Electric C-1450A is an AC operated 5 tube BC band clock radio. The BC band range is 540 to 1600 kHz. Has built-in loop antenna. Has Qty(1) PM 3.5" speaker and Qty(1) PM 4" speaker. Cabinet color is Bell White.
The following models use the same schematic and cabinet but have different cabinet colors:
Model Number Cabinet Color C-1450A Bell White C-1451A Honey Beige C-1452A Nutmeg Brown
- Literature/Schematics (1)
- GE 1966/1967 FM/AM Clock and Table Radios catalog
- Literature/Schematics (2)
- General Electric Service Notes (General Electric Service Guide Volume VI 1965 to 1967 Pages 30 to 31)
