- Country
- United States of America (USA)
- Manufacturer / Brand
- General Electric Co. (GE); Bridgeport CT, Syracuse NY
- Year
- 1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 42110
-
- Brand: Musaphonic
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 9
- Main principle
- Superhet with RF-stage; ZF/IF 465 kHz; 2 AF stage(s)
- Tuned circuits
- 8 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Details
- Radio with other functions
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
- Power out
- 2.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: G97 - General Electric Co. GE;
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 28.2 x 41.5 x 14 inch / 716 x 1054 x 356 mm
- Notes
- The General Electric model G97 has BC (540 - 1640 kHz), "Amateur-Aircraft" (1600 - 5650 kHz) and SW (5.6 - 18.0 MHz) bands. Five knobs in a row, below seven push-button station selectors. Separate oscillator, var. AFC. Clock above right when opening lid.
- Net weight (2.2 lb = 1 kg)
- 42.6 kg / 93 lb 13.3 oz (93.833 lb)
- External source of data
- Ernst Erb
- Source of data
- Collector's Guide to Antique Radios 4. Edition
- Circuit diagram reference
- Rider's Perpetual, Volume 9 = 1938 and before
