H-91 Longfellow Grandfather Clock

General Electric Co. (GE); Bridgeport CT, Syracuse NY

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
General Electric Co. (GE); Bridgeport CT, Syracuse NY

Year
1931

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
42269

- Brand: Musaphonic

Schematics

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421052) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421053) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421054) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421055) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421056) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421057) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421058) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421060) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 421062) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (3)

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 266873) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (2)
By courtesy of William Kendrick, USA

H-91 Longfellow Grandfather Clock; General Electric Co. (ID = 266874) Radio — General Electric Co. H-91 Longfellow Grandfather Clock (2)
By courtesy of William Kendrick, USA

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
10

Valves / Tubes
35 24 27 35 35 27 47 47 80 27

Main principle
Superhet with RF-stage; ZF/IF 175 kHz

Wave bands
Broadcast only (MW).

Power type and voltage
Alternating Current supply (AC) / 115 Volt

Loudspeaker
Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

Power out
4 W (unknown quality)

Material
Wooden case

from Radiomuseum.org
Model: H-91 Longfellow Grandfather Clock - General Electric Co. GE;

Shape
Grandfather Clock with Radio.

Dimensions (WHD)
17.5 x 78 x 14.3 inch / 445 x 1981 x 363 mm

Net weight (2.2 lb = 1 kg)
62 kg / 136 lb 9 oz (136.564 lb)

Price in first year of sale
254.00 $

External source of data
Ernst Erb

Source of data
Radio Collector`s Guide 1921-1932

Circuit diagram reference
Rider's Perpetual, Volume 4 = ca. 1934 and before

Mentioned in
The Radio Collector's Directory and Price Guide 1921 - 1965

Literature/Schematics (1)
Collector's Guide to Antique Radios (6th edition)
