• Country
• United States of America (USA)

• Manufacturer / Brand
• General Electric Co. (GE); Bridgeport CT, Syracuse NY

• Year
• 1962 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 89708

• • Brand: Musaphonic

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• 12AT7 12AX7 6EW6 6EZ8 6AU6 6BA6 6AU6 12AX7 7189A 7189A 5Y3GT

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Changer (Record changer); Hi-Fi equipment

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• 6 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: RC3230A Console - General Electric Co. GE;

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• The RC3230A Console is one model from a series of consoles with an AM/FM Stereo Tuner, Amplifier, Speakers, and a Record Changer.

  The console series includes: RC3230A (Mahogany Standard), RC3231A (Walnut), RC3232A (Maple), RC3233A (Oak), and MC3235A (Mahogany Antique).

  Tuner Model: TU-20D.

  Record Changer Model: Glaser-Steers GS-77 Revised.

  Tubes listed are for the Tuner, MPX, and Amplifier.

  Two 6"x9" Forward facing speakers plus four 3" diameter tweeters mounted on the sides.

• Circuit diagram reference
• Beitman Radio Diagrams Vol. 23, 1963

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 642, Folder 7, Aug. 1963.)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
