Solid State Clock Radio C2420D-LT.Beige 50 Hz version

General Electric Co. (GE); Bridgeport CT, Syracuse NY

Data

Forum

Pictures

Collections

Country
United States of America (USA)

Manufacturer / Brand
General Electric Co. (GE); Bridgeport CT, Syracuse NY

Year
1969 ?

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
355211

- Brand: Musaphonic

Schematics

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042584) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042587) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042594) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)
Leider fehlt das Typenschild.

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042585) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042586) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042588) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042589) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042590) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042591) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042592) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042593) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042595) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042597) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042596) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042598) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042599) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)
Elektro-Lumineszenz-Platte, Vorderseite.

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042600) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)
Elektro-Lumineszenz-Platte, Rückseite.

Solid State Clock Radio C2420D-LT.Beige; General Electric Co. (ID = 3042601) Radio — General Electric Co. Solid State Clock Radio C2420D-LT.Beige (1)

Technical Specifications

Number of Transistors
5

Semiconductors

Main principle
Superheterodyne (common); Export model

Wave bands
Broadcast only (MW).

Power type and voltage
Alternating Current supply (AC) / 50 Hz, 115 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: Solid State Clock Radio C2420D-LT.Beige [50 Hz version] - General Electric Co. GE;

Shape
Tablemodel with Clock ((Alarm-) Clock Radio).

Dimensions (WHD)
247 x 137 x 140 mm / 9.7 x 5.4 x 5.5 inch

Notes
Exportmodell für die US-Soldaten in Deutschland. Das Uhrwerk (Hersteller Telechron) ist für 50 Hz angepasst.
Das Modell besitzt eine Hinterleuchtung des Zifferblattes mittels Elektro-Lumineszenz-Platte.
Ähnliche Modelle sind: C4403A und C1480B, mit ähnlichem Schaltplan.

Export model for the US soldiers in Germany. The clock is adapted for 50 Hz.
The dial of this model is backlit by means of an electro-luminescent plate.
Models with similar circuit diagram are: C4403A and C1480B.

Made in Singapore

See also the 60 Hz version.

Net weight (2.2 lb = 1 kg)
1.2 kg / 2 lb 10.3 oz (2.643 lb)

Literature/Schematics (1)
Photofact Folder, Howard W. SAMS (Set 1121, Folder 3, Oct. 1970.)
