• Country
• United States of America (USA)

• Manufacturer / Brand
• General Motors Radio Corp.

• Year
• 1931

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 103803

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 10

• Valves / Tubes
• 35 27 24 35 35 27 27 45 45 80

• Main principle
• Superhet with RF-stage; ZF/IF 175 kHz

• Tuned circuits
• 10 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Queen Anne 254 Ch= S-3B - General Motors Radio Corp.

• Shape
• Console, Lowboy (legs < 50 %).

• Notes
• 25 cycles. Push-pull af output.

• Source of data
• Radio Collector`s Guide 1921-1932

• Circuit diagram reference
• Rider's Perpetual, Volume 2 = 1932 (Models 1931/1932)

• Mentioned in
• The Radio Collector's Directory and Price Guide 1921 - 1965

• Literature/Schematics (1)
• Rider's Perpetual, Volume 5 = ca. 1934 and before

• Author
• Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
