Cromwell 256 Ch= S-3A
General Motors Radio Corp.
- Country
- United States of America (USA)
- Manufacturer / Brand
- General Motors Radio Corp.
- Year
- 1931
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 103807
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz
- Tuned circuits
- 10 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Cromwell 256 Ch= S-3A - General Motors Radio Corp.
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
- 60 cycles. Push-pull af output.
- Price in first year of sale
- 160.00 $
- Source of data
- Radio Collector`s Guide 1921-1932
- Circuit diagram reference
- Rider's Perpetual, Volume 2 = 1932 (Models 1931/1932)
- Literature/Schematics (1)
- Rider's Perpetual, Volume 5 = ca. 1934 and before
- Author
- Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.
