Signal generator 605-A All Versions
General Radio Company; Cambridge (MA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- General Radio Company; Cambridge (MA)
- Year
- 1936
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 112252
-
- alternative name: GenRad
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Other, details in remarks or not known.
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Signal generator 605-A [All Versions] - General Radio Company;
- Shape
- Tablemodel, low profile (big size).
- Notes
- General Radio 605A Signal Generator;
Frequency generator, 9.5 kHz up to 30 MHz, 400 Hz internal or ext. modulation 30 - 15.000 Hz, Versions available for 42, 50, 60 Hz mains power or battery DC operation. The General Radio model 605-A was replaced by the model 605-B, which was sold at least in 1940.
- Price in first year of sale
- 415.00 $
- Source of data
- -- Original prospect or advert
- Author
- Model page created by a member from I. See "Data change" for further contributors.
