- Country
- Spain
- Manufacturer / Brand
- General Eléctrica Española (GEE); Madrid
- Year
- 1965
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 301704
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 19
- Valves / Tubes
- EC88 EC86 ECC189 ECF801 EF183 EF183 EF184 EL183 EF184 ECH84 EF184 EB91 ECC82 EL502 EY88 EY86 ECL85 ECL86 23AXP4
- Number of Transistors
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz; 2 AF stage(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 127; 150; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Wooden case
- from Radiomuseum.org
- Model: 5Z3 - General Eléctrica Española GEE
- Shape
- Tablemodel, low profile (big size).
- Notes
-
TV B/N con selector rotativo de VHF, sintonizador a válvulas para UHF y TRC de 23"
Altavoz elíptico de 5" x 8"Veanse variantes:
5Z3 Anexo 1 con sintonizador transistorizado de UHF
5Z3 Anexo 2 con sintonizador de UHF y selector de VHF diferentes.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
- Other Models
-
Here you find 72 models, 31 with images and 67 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from General Eléctrica Española (GEE); Madrid
