CMR-2 1971

• Country
• Spain

• Manufacturer / Brand
• General Eléctrica Española (GEE); Madrid

• Year
• 1971

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 290425

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 0

• Valves / Tubes
• A20_LDR

• Number of Transistors
• 24

• Semiconductors
• SF294 SF295 SC149 BC148 2N3794 2N3794 2N3794 2N3794 BC209 AC180 BC209 2N4288 2N4288 AC180 AC180 BC208 BC208 BC208 BC208 BC208 MC140 2N3794 AC181 AC180 BB100 BZY63 BZY88 B30C350 SD60 SFD107 SFD112 SZ6 1N542

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 6 x 1,5 / 12 / 127; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Power out
• 0.6 W (undistorted)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: CMR-2 [1971] - General Eléctrica Española GEE

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 300 x 200 x 80 mm / 11.8 x 7.9 x 3.1 inch

• Notes

• OM: 535 - 1.645 kHz.
  FM: 85 - 105 MHz.

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.

• Other Models

• Here you find 72 models, 31 with images and 67 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from General Eléctrica Española (GEE); Madrid
