• Country
• Spain

• Manufacturer / Brand
• General Eléctrica Española (GEE); Madrid

• Year
• 1968 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 290554

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• ECL86 EZ80

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Rec.Player+Audio.Amp+LS

• Power type and voltage
• Alternating Current supply (AC) / 110: 127; 160; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch

• Power out
• 2.5 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: MM-4 - General Eléctrica Española GEE

• Shape
• Tablemodel, low profile (big size).

• Notes

•  Electrófono monoaural manual de 4 velocidades equipado con cápsula cerámica monofónica. Puede funcionar en estéreo usando la salida auxiliar ST para alimentar un segundo amplificador y cambiando la cápsula por una estereofónica.

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
