• Country
• Great Britain (UK)

• Manufacturer / Brand
• General Electrical Radio Co. Ltd. & General Sonic Industries; London

• Year
• 1946–1949 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 109111

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• 12SK7 12J7 35L6 166G

• Number of Transistors

• Semiconductors
• Tr.Gl.=Metal-rectif.

• Main principle
• TRF (Tuned-Radio-Frequency but use of regeneration unknown)

• Tuned circuits
• 2 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 200-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: Mighty Midget - General Electrical Radio Co.

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 8.5 x 7 x 4.5 inch / 216 x 178 x 114 mm

• Notes

• Different chassis versions and rectifiers known.

  Barretter 166G (aequivalent with LU42D280) is also used as pilot light. It has a SES base.

  Price: 6£ 19s 9d
  A frame aerial is provided.

• Mentioned in
• -- Original prospect or advert (1946)
