• Country
• Denmark

• Manufacturer / Brand
• Geodyn; (Where?)

• Year
• 1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 309139

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 3

• Valves / Tubes
• CF7 CL4 CY1

• Main principle
• Detector with Vacuum Tube (Valve), no tuner; none

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 110; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: 2 UK - Geodyn; Where?

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 355 x 215 x 180 mm / 14 x 8.5 x 7.1 inch

• Notes

• A pre war model in art deco style.

  Wooden, box shaped cabinet, covered with faux leather (Pluviusin) in red, blue or green.

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Price in first year of sale
• 165.00 DKK

• Mentioned in
• Article in "Resonans, vol. 1 2015"

• Author
• Model page created by Egil Hansen. See "Data change" for further contributors.
