Complex Ratio Bridge CBR-4
Gertsch Products Inc.; Los Angeles (CA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Gertsch Products Inc.; Los Angeles (CA)
- Year
- 1965 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 306883
Internal view.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Power type and voltage
- Line / Storage batteries (perhaps also batteries) / 115; 12 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Complex Ratio Bridge CBR-4 - Gertsch Products Inc.; Los
- Shape
- Rack
- Notes
-
Complex ratio bridge intended for the calibration of synchro resolvers. It generates two sinusoids phase shifted by 90 degrees. Two precision transformer dividers are used to compare the output of synchro resorver windings against the internal quadrature references.
The set uses two ESI 'Dekatran' precision variable transformers, each with four-digit resolution. Due to the use of transformers, its accuracy depends to a great extent upon the turns of each intermediate tap.
12 V internal storage battery. Built-in AC battery charger.
- Author
- Model page created by Emilio Ciardiello. See "Data change" for further contributors.
