• Country
• United States of America (USA)

• Manufacturer / Brand
• Gibson Manufacturing Co., Kalamazoo (MI)

• Year
• 1965

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 182018

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 12AX7 12AX7 6BQ5 6X4

• Main principle
• Audio-Amplification

• Power type and voltage
• Alternating Current supply (AC) / 110-120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm

• Power out
• 5 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: Kalamazoo Model Two - Gibson Manufacturing Co.,

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 350 x 420 x 180 mm / 13.8 x 16.5 x 7.1 inch

• Notes
• wie Model One, jedoch mit Tremolo-Zusatz.

• Net weight (2.2 lb = 1 kg)
• 4.8 kg / 10 lb 9.2 oz (10.573 lb)

• Author
• Model page created by Hannes Gerber. See "Data change" for further contributors.
