• Country
• United States of America (USA)

• Manufacturer / Brand
• Gilfillan Bros.Inc.; Los Angeles (CA)

• Year
• 1932 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 310265

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 26 26 27 26 71 80

• Main principle
• TRF with diode detector

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• Magnetic loudspeaker (reed) generic. / Ø 8 inch = 20.3 cm

• Power out
• 0.4 W (0.78 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Syrene? - Gilfillan Bros.Inc.; Los

• Shape
• Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).

• Dimensions (WHD)
• 13.5 x 17 x 8 inch / 343 x 432 x 203 mm

• Net weight (2.2 lb = 1 kg)
• 13 lb 14 oz (13.875 lb) / 6.299 kg

• Author
• Model page created by Michael Boessen. See "Data change" for further contributors.
