• Country
• Germany

• Manufacturer / Brand
• Goldhand (Marke / brand); Düsseldorf

• Year
• 1990 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 287639

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• CS9018 CS9018 CS9018 CS9011 CS9014 CS9015 CS9013 CS9012 1N60 1N60 1N4148 1N4148

• Main principle
• Superhet with RF-stage; ZF/IF 10700 kHz

• Tuned circuits
• 7 FM circuit(s)

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Dry Batteries / 3 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch

• Power out
• 0.25 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: UKW Reise-Radio TR100 - Goldhand Marke / brand;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 165 x 80 x 33 mm / 6.5 x 3.1 x 1.3 inch

• Notes

• Siehe auch ähnliches Modell ICS/SEC TR-611 (UKW/MW)

  Wahrscheinlich Hersteller aus Fernost.

• Net weight (2.2 lb = 1 kg)
• 0.220 kg / 0 lb 7.8 oz (0.485 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Jörg Kulbe. See "Data change" for further contributors.
