• Country
• Great Britain (UK)

• Manufacturer / Brand
• Goodmans Industries Ltd.; Wembley, Middlesex

• Year
• 1975 ??

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 288450

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 4 Loudspeakers

• Power out
• 35 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Meta 800-S - Goodmans Industries Ltd.;

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 320 x 600 x 290 mm / 12.6 x 23.6 x 11.4 inch

• Notes

• Goodmans HiFi Stand-Regalbox Modell Meta-800-S.
  Frequenzgang 30 - 22000 Hz
  Impedanz 4 - 8 Ω
  Belastbarkeit 35 W Sinus
  Bestückung:
  2x Bass (Coat-Cone)
  1x Mitteltöner
  1x Hochtöner (Dome)
  3-Weg Frequenzweiche
  Ausführung:
  Holzgehäuse in Nußbaum Natur (DM 645,--) oder in
  Schleiflack weiss (DM 695,--)



• Mentioned in
• -- Original prospect or advert (Goodmans Catalogue 70')

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
