• Country
• United States of America (USA)

• Manufacturer / Brand
• Goodrich, B.F.; Akron,Ohio

• Year
• 1950 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 111566

• • Brand: Mantola

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 7F8 6BA6 6BA6 6AL5 6BE6 6AT6 6V6 5Y3

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 117 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

• Power out
• 3.5 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 93-107 - Goodrich, B.F.; Akron,Ohio

• Shape
• Console, Lowboy (legs < 50 %).

• Notes
• Color=Blond

• Circuit diagram reference
• Rider's Perpetual, Volume 19 = 1949 and before

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
