• Country
• United States of America (USA)

• Manufacturer / Brand
• Goodrich, B.F.; Akron,Ohio

• Year
• 1950 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 117475

• • Brand: Mantola

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• 6BA6 6BE6 6SG7 6SG7 6H6 6SQ7 6V6GT 5Y3GT

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 105 - 125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm

• Power out
• 3.5 W (unknown quality)

• from Radiomuseum.org
• Model: R-78262 - Goodrich, B.F.; Akron,Ohio

• Notes
• Record Changer: Detrola Model 7000.

• Circuit diagram reference
• Rider's Perpetual, Volume 18 = 1949 and before

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
